Applications
Cargo e-bike
Technical Data
| Voltage (nominal) | 48 V |
| Capacity (nom.) | 34 Ah |
| Energy (nom.) | 1600 Wh |
| Topology | 13S6P |
| Soc | Yes |
| Connector | Customized |
| Technologies | NMC |
| Mass | <8 kg |
| Dimensions (L x W x H) | 450 x 220 x 85 mm |
| Housing | Plastic |
| Communication | CAN |
What is the Universal Cargo 48 V, 34 Ah battery system designed for?
The Universal Cargo 48 V, 34 Ah battery system is designed for cargo e-bikes used in urban transport and logistics. With 34 Ah capacity and 1600 Wh of energy, it supports extended range, heavy-duty use and reliable performance in demanding city environments.
What are the key technical specifications of this battery system?
The battery system has a nominal voltage of 48 V, a nominal capacity of 34 Ah and nominal energy of 1600 Wh. It uses a 13S6P topology, NMC technology and CAN communication, with a mass of less than 8 kg and dimensions of 450 x 220 x 85 mm.
How does the battery support safe and efficient operation?
The system is equipped with an advanced BMS that provides real-time monitoring, cell balancing, thermal management and fault detection. These features help maximize battery efficiency, safety and cycle life.
Can the Universal Cargo 48 V, 34 Ah battery system be customized?
Yes. The battery is designed as a flexible platform that can be further developed and customized to meet specific customer requirements. This includes adapting the form factor, communication protocols, BMS functionality, connector and packaging.
Advanced BMS
Advanced BMS provides real-time monitoring, cell balancing, thermal management, and fault detection to maximize battery efficiency, safety, and cycle life.
High energy density
High energy density lets cargo batteries store more power with less weight, boosting range and payload capacity.
